Waterproof remote I/O compatible with digital I/O, analog I/O and IO-Link master. Up to 18 units can be added for use. Diagnosis information (overcurrent, short-circuit, error, etc.) can be acquired, contributing to the IoT of equipment.
Supported communications: EtherNet/IP, EtherCAT, IO-Link (as a network between the IO-Link master unit and the subordinate IO-Link devices)
Maximum number of connected units: 18
Features Include:
Max. connection units: 18
Can be used in combination with the required units.Power supply units can be added according to the power supply requirements of sensors connected to remote I/O.
- Count units as connection units: Digital I/O, analog I/O, IO-Link master
- Do not count units as connection units: Power supply units, end units
- Device unit input/output points: 512byte (4096 points) * Total input/output value.
Waterproof remote I/O IP65/67:M12 connector and M8 connector are adopted. Since the control panel is not required, control panel cost can be reduced.
IO-Link master:8 ports per unit. Since only the IO-Link master can be expanded, up to 136 IO-Link components can be connected to one device unit.
The IO-Link master can occupy up to 64 bytes (512 points)/unit. Data size per port can be adjusted according to the data size of IO-Link components.
Easy-to-use design:I/O status is displayed with 3-color LEDs
- Green: Normal
- Red: Error (disconnection, communication error, etc.)
- Orange: Information (exceeding the set value, etc.)
Device unit setting tool:Software (RTXTools) for setting and monitoring the device unit, IO-Link master and each unit is available free of charge from the CKD website.
